Palladium
LINDLAR CATALYST · Palladium on activated charcoal · 10%Pd · Rosenmund catalyst · PALLADIUM 10% ON CARBON · Paladium · 5% PALLADIUM ON CARBON · PALLIDIUM
Identifiers & Physical Properties
| CAS No. | 7440-05-3 |
|---|---|
| Molecular formula | Pd |
| Average molar mass | 106.42 g/mol |
| Monoisotopic mass | 105.90348 g/mol |
| SMILES | [Pd] |
| InChIKey | KDLHZDBZIXYQEI-UHFFFAOYSA-N |
| PubChem CID | 23938 |
| ChEBI | CHEBI:33363 |
| EC No. | 231-115-6 |
| DTXSID | DTXSID4064680 |
Chemical & Physical Properties
| Topological polar surface area | 0 |
|---|---|
| Hydrogen bond donors | 0 |
| Hydrogen bond acceptors | 0 |
| Rotatable bonds | 0 |
| Heavy atoms | 1 |
| Formal charge | 0 |
| Complexity | 0 |
| Density | 12.02 g/cu cm12 @25 °C1.025 g/mL at 25 °C |
| Color/Form | Silver-white, ductile metalSteel whiteSilver-white metalcubic |
| Solubility | Soluble in aqua regia and fused alkaliesinsoluble in organic acidssoluble in aqua regia |
| Boiling point | 2963 °C2963 °C @760 [mm Hg]2970 °C(lit.) |
| Decomposition | No decomposition. /from table/ |
| Melting point | 1554.9 °C1554.8 °C1554 °C(lit.) |
| Vapor pressure | 3.47 Pa (0.0260 mm Hg) at 1552 °C |
| Physical Description | Steel-white metal that does not tarnish in airOxidation states: 2+ and 4+[Nordberg, p. 1113]Solid |
| Other Experimental Properties | Palladium is the lightest of the platinum group and very malleable and ductile when pure. It resists oxidation at ordinary temperatures. It absorbs a considerable amount of hydrogen gas. It is appreciably volatile at high temperatures. At red heat it is converted to the oxide.Stable isotopes: (102)Pd, 1.02%(1.4)Pd, 11.14%(105)Pd, 22.23%(106)Pd, 27.33%(108)Pd, 26.46%(110)Pd, 11.72%Usual valency, 2,4ionic radius, 65 pm, crystal structure, face-centered cubiclattice constant, 389 pmreflectance, 54%thermal expansion, 11.11X10+6 °C-1magnetic susceptibility, 5.23X10-6 cu cm/gwork function, 4.99 eVYoung's modulus, 1.24X10+8 kN/sq multimate tensile strength, 180-200 MPaPoisson's ratio, 0.39Vicker's hardness, 40temperature coefficient of resistance 3.8X10-3 K-1electrical resistivity at 0 °C, 9.93 microohm-cmthermal conductivity, 75 W/m KPalladium is stable in air, even at elevated temperaturesshows no corrosion or tarnishing in hydrogen sulfide atmospheres.For more Other Experimental Properties (Complete) data for PALLADIUM, ELEMENTAL (6 total), please visit the HSDB record page. |
| Storage conditions | no restrictions. |
| Physical state | wire |
| Specific gravity | 12.03 |
| Color | Silver-gray |
| Odor | Odorless |
| Resistivity | 9.96 μΩ-cm, 20°C |
| Electrical Conductivity | 1× 107S/m |
| Thermal conductivity | 71 W/(m·K) |
| Specific heat capacity | Cp(crystal): 0.24 J/(g·K)Cp(gas): 0.2 J/(g·K), at 25℃ |
| Merck | 14,6989 |
| Exposure limits | ACGIH: TWA 1 mg/m3OSHA: TWA 15 mg/m3TWA 5 mg/m3 |
| Stability | Stable. Flammable - fine powder may cause fire or explosion in air. Incompatible with ozone, sodium tetrahydroborate, sulphur, arsenic. |
| Cosmetics Ingredients Functions | COLORANT |
| InChI | 1S/Pd |
| InChIKey | KDLHZDBZIXYQEI-UHFFFAOYSA-N |
| SMILES | [Pd] |
| Hardness, Vickers | 37, Annealed105, Cold Drawn |
| Modulus of Elasticity | 117 GPa |
| Poissons Ratio | 0.39 |
| Shear Modulus | 42.0 GPa, Calculated |
| CAS DataBase Reference | 7440-05-3(CAS DataBase Reference) |
| EWG's Food Scores | 4 |
| FDA UNII | S66WSD7L96 |
| NIST Chemistry Reference | Palladium(7440-05-3) |
| EPA Substance Registry System | Palladium (7440-05-3) |
| UNSPSC Code | 12352302 |
| NACRES | NA.23 |
| GHS pictogram | GHS07 |
| Signal word | Warning |
| GHS hazard statements | H315-H319 |
| GHS precautionary statements | P305+P351+P338 |
| Hazard symbols | T,F,Xi |
| Risk statements (R) | 61-33-37/38-40-41-36/37/38-11 |
| Safety statements (S) | 53-26-36/37/39-24/25-36-22 |
| UN transport number | UN 3089 4.1/PG 2 |
| Water hazard class (WGK) | nwg |
| RTECS number | RT3480500 |
| Autoignition temperature | >1120 °F |
| TSCA inventory status | TSCA listed |
| Hazard class | 4.1 |
| Packing group | III |
| Customs code | 28439000 |
| Storage class | 13 - Non Combustible Solids |
| Hazardous substances data | 7440-05-3(Hazardous Substances Data) |
| Toxicity | LD50 oral (rat) 200 mg/kg (palladium chloride) LC50 intratracheal (rat) 6 mg/kg (palladium chloride) |
| REACH registrations | Active |
| Limited quantities | 1.0 Kg (2.2 lbs) |
| Excepted quantities | Max Inner Pack (30g or 30ml) and Max Outer Pack (500g or 500ml) |
Safety & Regulations
| GHS classification | This chemical does not meet GHS hazard criteria for 59.3% (365 of 616) of all reports.DangerH228 (31.5%): Flammable solid [Danger Flammable solids]H315 (17.7%): Causes skin irritation [Warning Skin corrosion/irritation]H319 (18%): Causes serious eye irritation [Warning Serious eye damage/eye irritation]H335 (15.9%): May cause respiratory irritation [Warning Specific target organ toxicity, single exposureRespiratory tract irritation]H413 (17%): May cause long lasting harmful effects to aquatic life [Hazardous to the aquatic environment, long-term hazard]P210, P240, P241, P261, P264, P264+P265, P271, P273, P280, P302+P352, P304+P340, P305+P351+P338, P319, P321, P332+P317, P337+P317, P362+P364, P370+P378, P403+P233, P405, and P501 (click each P-code to see the statement)Aggregated GHS information provided per 616 reports by companies from 26 notifications to the ECHA C&L Inventory. Each notification may be associated with multiple companies.Reported as not meeting GHS hazard criteria per 365 of 616 reports by companies.There are 24 notifications provided by 251 of 616 reports by companies with hazard statement code(s).Information may vary between notifications depending on impurities, additives, and other factors. The percentage value in parenthesis indicates the notified classification ratio from companies that provide hazard codes. Only hazard codes with percentage values above 10% are shown. For more detailed information, please visit ECHA C&L website. |
|---|---|
| Regulatory information | Chemical: PalladiumRegulation (EC) No 1935/2004 (amended)Status: Active Update: 27-06-2022 https://echa.europa.eu/registration-dossier/-/registered-dossier/18747Palladium: Does not have an individual approval but may be used under an appropriate group standard |
| Other safety information | IMAP assessments - Palladium: Environment tier I assessmentIMAP assessments - Palladium: Human health tier I assessment |
| Fire potential | Combustible in the form of dust when exposed to heat or flame.Finely divided palladium (palladium black) used as a hydrogenation catalyst is usually pyrophoric and needs appropriate handling precautions. |
| Hazards summary | Possible skin sensitizerDust can be a fire and explosive hazard[HSDB] Occupational asthma has been reported, but its incidence is very low. Palladium II chloride is a stronger skin sensitizer than nickel sulfate. [Nordberg, p. 1113, 1119] The metals in this group [platinum, palladium, iridium, osmium, rhodium, and ruthenium] generally are nontoxic in the metallic state, but the soluble halide salts (particularly of Pt) and osmium tetroxide are highly reactive. Exposure to these elements results in hypersensitivity allergic reactions in susceptible individuals. [Sullivan, p. 911] Tram drivers in Rome were exposed to Pt, Rh and Pd from catalytic converters at levels about 10 times lower than those known to cause adverse effects in workers. [PMID 18849761] See Palladium tetraamine dichloride. |
| FDA requirements | Noble metal alloy: (a) Identification. A noble metal alloy is a device composed primarily of noble metals, such as gold, palladium, platinum, or silver, that is intended for use in the fabrication of cast or porcelain-fused-to-metal crown and bridge restorations. (b) Classification. Class II (special controls). The special control for these devices is FDA's "Class II Special Controls Guidance Document: Dental Noble Metal Alloys." The devices are exempt from the premarket notification procedures in subpart E of part 807 of this chapter subject to the limitations in §872.9. See §872.1(e) for availability of guidance information. /Noble metal alloy/ |
| Hazard Classes and Categories | Flam. Sol. 1 (31.5%)Skin Irrit. 2 (17.7%)Eye Irrit. 2 (18%)STOT SE 3 (15.9%)Aquatic Chronic 4 (17%) |
| Explosive Limits and Potential | Explosive reaction with hydrogen and hydrogen peroxide. |
| Skin, Eye, and Respiratory Irritations | Contact dermatitis has been associated with metallic palladium, especially with palladium alloys ... . |
| Hazardous Reactivities and Incompatibilities | Incompatibilities: Arseniccarbonozonidesmethanolsulfur.Reaction with formic acid or tetrahydroborate releases explosive hydrogen gas.Violent reaction with isopropyl alcohol or OF2S.At a red heat is converted in to the monoxide. Forms dihalides with fluorine or chlorine at a red heat. Reacts with nitric acid, sulfuric acid, a mixture of hydrochloric and choric acids. Reacts slightly with concentrated /hydrochloric acid/more readily in the presence of air or free chlorine. Forms a sulfide when heated with sulfur, a phosphide when heated with phosphorus. Absorbs a considerable amount of hydrogen. |
| CSL Reaction Information | CSL00027METHANOL + PALLADIUMPalladium on carbon (10%) is highly pyrophoric under hydrogen atmosphere and to some extent in air. Palladium on carbon (Pd/C) frequently ignites when it first comes in contact with methanol (and to a lesser extent, any flammable organic solvent) and as such represents a significant safety risk.M (up to 100g)Addition of Pd/C (10% wet) to the reaction flask containing hydrogen atmospehere (additional catalyst addition to the ongoing reaction in 100 mL methanol) resulted is small fire. |
| Disposal methods | SRP: The most favorable course of action is to use an alternative chemical product with less inherent propensity for occupational exposure or environmental contamination. Recycle any unused portion of the material for its approved use or return it to the manufacturer or supplier. Ultimate disposal of the chemical must consider: the material's impact on air qualitypotential migration in soil or watereffects on animal, aquatic, and plant lifeand conformance with environmental and public health regulations. |
| Protective Action Criteria (PAC) | 1.5 [mg/m3]160 [mg/m3]970 [mg/m3] |
| Health effects | Contact with palladium may cause palladium sensitivity and allergy. Animal studies have shown that palladium may damage the liver and kidney. (L798) |
| Exposure routes | Inhalation (A21)oral (A21)dermal (A21) |
| Toxicity summary | IDENTIFICATION: Palladium is a steel white ductile metallic element. It is stable in air and resistant to attack by most reagents. It is soluble in a mixture of hydrochloric and nitric acids. Palladium and its alloys are used as catalysts in the petrochemical and automotive industries. Used in electronics and in dental applications. Purified metals between 99.9% and 99.99% are available for chemical use as foil, granules, rod or wire. HUMAN EXPOSURE: The general population is primarily exposed to palladium through dental alloys, jewlery, food and emissions from automobile catalytic converters. There are limited data concerning the distribution of palladium from dental resorations in human tissues or fluids. Populations at special risk of palladium allergy include people with known nickel allergy. ANIMAL STUDIES: Six months after a single intratracheal application of palladium dust, several histopathological signs of inflammation were noted in the lungs of rats. Daily oral administration of palladium dust over 6 months resulted in changes in several blood and urine parameters. Palladium applied in its metallic form showed no or little cytotoxicity.[Palladium ions are able to inhibit most major cellular fuctions. They form strong complexes with both inorganic and organic ligands, substitute essential ions, bind to amino acids and various enzymes including creatine kinase and prolyl hydroxylase, and interact with functional groups of other macromolecules such as DNA leading to strand breakage. (L798) |
| Signs and Symptoms | Skin contact with palladium may cause contact dermatitis, erythema, and oedema. (L798) |
| Natural Pollution Sources | Palladium (Pd) is found with platinum, gold, and nickel ores.Palladium belongs to the platinum group metals (ruthenium, osmium, rhodium, iridium, palladium and platinum), which are rare elements often found together in nature(1). In the lithosphere, the estimated concentration of platinum group metals range from 0.05 to 0.5 ppm(2). Palladium's abundance in the earth's crust is 0.001-0.01 ppm(3). |
| Human Toxicity Excerpts | /CASE REPORTS/ A 54-yr-old woman patient had symptoms of stomatitis and asthma following the provision of a dental prosthesis in July 1991. ...A positive patch test reaction /was found/ to palladium only, without any concomitant metallic contact dermatitisin particular there was no sensitization to nickel. This is a very rare sensitization. After replacement of the dental alloy the clinical symptoms improved./CASE REPORTS/ Granulomatous tissue reactions due to jewelry made of gold, silver, nickel and palladium are rare but nevertheless have been known for a long time. A female patient developed nodular infiltrates after having been pierced with ear stickers containing palladium. A contact allergic reaction could be demonstrated as the underlying cause by inducing similar histological changes following patch testing with palladium./CASE REPORTS/ A patient with a metal dental bridge complained of itching and pain in the oral cavity. She suffered also from recurrent blisters, ulceration, and infection of the oral mucous membrane. Skin tests carried out ... on this patient showed... a positive allergic reaction to... palladium metal./CASE REPORTS/ ...A case of linear lichen planus extending from the right cheek to the jaw, which was accompanied by itching and an unusual sensation in the mouth /is described/. The eruption was located along the mandible and aligned with the mandibular nerve. The right molars of the patient contained metal compounds and these were considered to be the cause of his disease. Patch testing with various dental metals showed positive reactions to palladium and platinum. A biopsy specimen showed a lichenoid reaction in the lesional tissue, and dermal contact dermatitis was noted at the palladium patch test site. His dentist reported that palladium-silver-gold or nickel-chrome alloys without platinum had been used in the crown and bridge of his molars. After removal of the dental alloys, the skin eruption resolved with some residual hyperpigmentation. In addition, the peculiar mouth sensation disappeared dramatically within 2 months.For more Human Toxicity Excerpts (Complete) data for PALLADIUM, ELEMENTAL (11 total), please visit the HSDB record page. |
| Carcinogen Classification | No indication of carcinogenicity to humans (not listed by IARC). |
| Non-Human Toxicity Excerpts | /LABORATORY ANIMALS: Acute Exposure/ Palladium powder /was given to/ rats by enteral (intragastric) /administration/ dose not specified. Clinical signs and toxic effects /include/: necrobiotic changes in the mucous membranes of the gastrointestinal tract, granular dystrophy of hepatocytes, swelling in the epithelium of kidney tubules. /from table//LABORATORY ANIMALS: Subchronic or Prechronic Exposure/ 6 months after a single intratracheal application of 50 mg palladium dust (about 143 mg/kg bw), the lungs of rats (Sprague-Dawley, female, n=10) were histopathologically examined. There were several signs of inflammatory responses (peribronchial inflammation, lymphocyte infiltration, interstitial pneumonia, formation of granulomata) observed, but no indications of interstitial fibrosis... ./LABORATORY ANIMALS: Subchronic or Prechronic Exposure/ Acute toxicity tests with 6 different palladium-containing dental alloys (pulverizedmean particle size 200 umpalladium content: 9-80 mass %) have been performed with rats (Wistar, n=105 females, 5 males). Oral doses of 200 mg/kg bw (in gelatin capsules) did not cause deaths or apparent toxic signs. Histopathological changes in lung, liver and kidney of rats (Sprague-Dawleyn=14) were seen 5 weeks after single oral administration of cut dental alloy material (1 g/kg bw, in gelatin capsules6 different alloysparticle size not specified), which contained palladium at 2.5-4 weight % and total noble metals (gold, palladium) at 44-62%. However, alloys of a higher noble metal (gold, palladium, platinum) content (78-97%) containing palladium at 4-26.5% did not elicit significant effects./LABORATORY ANIMALS: Subchronic or Prechronic Exposure/ Six different pulverized palladium-containing dental alloys have been tested for their subacute toxicity in rats (Wistar, n=10, 5 females, 5 males). Compared with controls, all specimens caused significant histopathological changes in lung, liver, kidney, small intestine and colon following daily oral doses of 1000 mg/kg bw for 7 days (and sacrifice after 7 additional days). The strongest effects were seen with compositions containing copper and/or indium: Pd73, Cu14, In5Pd74, Sn16, Cu9and Au51, Pd39, In4-9. The weakest effects were observed for the Pd58, Ag30, Sn6 alloy, and the changes due to the Pd80, Sn7, Ga6-8 and Au77, Pt10, Pd9 alloys fell in between. Some histocompatibility tests have been performed with several implants of palladium-containing dental alloys of different compositions. Four to 12 weeks after sc implantation of the experimental alloys into guinea-pigs, mice, or rats, or after intramuscular implantation into rabbits, the tissue reactions at the implantation site varied from slight to severe. The most extreme reactions were recorded when copper and/or indium were present as additional components. Altogether, the contribution of palladium to adverse effects of dental mixtures is not clear.For more Non-Human Toxicity Excerpts (Complete) data for PALLADIUM, ELEMENTAL (9 total), please visit the HSDB record page. |
| Populations at Special Risk | People with known metal (especially nickel) allergy may have an increased risk of palladium allergy. |
| Probable Routes of Human Exposure | Palladium concentrations in personal samples collected in 1996 during industrial operations involving the handling of palladium compounds were reported to be between 0.4 and 11.6 ug Pd/cu m as a 8-hour time-weighted average(1). Mean palladium concentrations of 3.5 ug/cu m, with local exhaust ventilation, and 5.5 ug/cu m, without dust control, were measured in the breathing zone of dental technicians(1). Palladium concentrations in air in a platinum and palladium refinery in New Jersey ranged from 0.001 to 0.36 ug/cu m(1). |
| Other Environmental Concentrations | Dust samples were collected in 1985 from the surfaces of plants along side roads in San Diego, CApalladium concentrations ranged from 0.015 mg/kg dry weight in dust collected along Bellaire Court, a residential street with light traffic, up to 0.28 mg/kg dry weight in dust collected approximately 2 ft from the edge of Interstate 5, a major freeway(1). Palladium concentrations of 0.001-0.146 mg/kg were reported in urban road dusts in Germany in 1995(2). |
| Antidote and Emergency Treatment | There are no established detoxification methods following poisoning by palladium or its compounds. Because of its poor absorption by the body, removal from exposure is the best remedy, when palladium is cleared by natural processes.Basic treatment: Establish a patent airway. Suction if necessary. Watch for signs of respiratory insufficiency and assist ventilations if needed. Administer oxygen by nonrebreather mask at 10 to 15 L/min. Monitor for pulmonary edema and treat if necessary ... . Monitor for shock and treat if necessary ... . Anticipate seizures and treat if necessary ... . For eye contamination, flush eyes immediately with water. Irrigate each eye continuously with normal saline during transport ... . Do not use emetics. For ingestion, rinse mouth and administer 5 ml/kg up to 200 ml of water for dilution if the patient can swallow, has a strong gag reflex, and does not drool ... . Cover skin burns with dry sterile dressings after decontamination ... . /Poison A and B/Advanced treatment: Consider orotracheal or nasotracheal intubation for airway control in the patient who is unconscious, has severe pulmonary edema, or is in respiratory arrest. Positive pressure ventilation techniques with a bag valve mask device may be beneficial. Monitor cardiac rhythm and treat arrhythmias as necessary ... . Start an IV with D5W /SRP: "To keep open", minimal flow rate/. Use lactated Ringer's if signs of hypovolemia are present. Watch for signs of fluid overload. Consider drug therapy for pulmonary edema ... . For hypotension with signs of hypovolemia, administer fluid cautiously. Watch for signs of fluid overload ... . Treat seizures with diazepam (Valium) ... . Use proparacaine hydrochloride to assist eye irrigation ... . /Poison A and B/ |
| Water hazard class (WGK) | nwg |
| TSCA inventory status | TSCA listed |
| RTECS number | RT3480500 |
| UN transport number | UN 3089 4.1/PG 2 |
| Customs code | 28439000 |
| Toxicity | LD50 oral (rat) 200 mg/kg (palladium chloride) LC50 intratracheal (rat) 6 mg/kg (palladium chloride) |
| Risk statements (R) | 61-33-37/38-40-41-36/37/38-11 |
| Signal word | Warning |
| GHS pictogram | GHS07 |
| Hazard symbols | T,F,Xi |
| Safety statements (S) | 53-26-36/37/39-24/25-36-22 |
| Hazard class | 4.1 |
| Storage class | 13 - Non Combustible Solids |
| Packing group | III |
| GHS hazard statements | H315-H319 |
| Limited quantities | 1.0 Kg (2.2 lbs) |
| Excepted quantities | Max Inner Pack (30g or 30ml) and Max Outer Pack (500g or 500ml) |
| REACH registrations | Active |
| Autoignition temperature | >1120 °F |
| GHS precautionary statements | P305+P351+P338 |
| Hazardous substances data | 7440-05-3(Hazardous Substances Data) |
Applications & Uses
Description
Palladium was discovered in 1803 by W.H. Wollaston during refining and purification of- platinum metal. This new metal was found in the aqua regia extract of native platinum and was detected in solution after platinum was precipitated. It was removed as ammonium chloroplatinate. Treating this solution with mercurous cyanide precipitated a yellow palladium complex salt. The precipitate was washed and ignited to form palladium metal. Wollaston named the element palladium after the newly discovered asteroid Pallas. Palladium in nature is always associated with other platinum group metals. Its abundance in earth's crust is estimated at 0.015 mg/kg, about three times more abundant than platinum. Palladium is used mostly in alloys and the majority of its alloys are used for electronics and telecommunications. They are contacts in electrical relays and automatic switching gear. Palladium-gold alloys are applied widely in dentistry and medicine. They are in devices for replacement of damaged bones and joints and as support in porcelain-overlay bridgework. Palladium alloys are used in decoration and jewelry as a substitute for gold. They are used in gems, watch cases and brooches. One of the most important applications of palladium is to catalyze hydrogenation, dehydrogenation, and petroleum cracking. Such reactions are widely employed in organic syntheses and petroleum refining. Palladium and platinum are installed in catalytic converters in automobiles to cut down the emission of unsaturated hydrocarbon gasses.
Occurrence
Palladium is considered a rare metal, making up only about 1 part per 100 million partsof the Earth’s crust. It is considered the 77th most abundant element on Earth, although it is seldom found in pure states. Rather, it is mixed with other metals or in compounds of palladium.It was originally found in gold ores from Brazil, where the miners thought the gold wascontaminated by what they referred to as “white gold.” Later, it was considered an alloy combinationof palladium and gold.Deposits of ores containing palladium, as well as other metals, are found in Siberia and theUral Mountains of Russia, Canada, and South Africa, as well as in South America.
History
Palladium is discovered by Wollaston in 1803. Palladium has a history that is sealed with that of platinum, with which it is found, and with which it is also associated as a member of the platinum metals group, also known as the nobel metals. “Native platinum” refers to the natively occuring platinum which is not actually pure platinum at all, but rather a natively alloyed mix of platinum group metals including palladium. Like gold, palladium can be beaten into leaf as thin as 1/250,000 in. The metal is used in dentistry, watchmaking, and in making surgical instruments and electrical contacts. Palladium recently has been substituted for higher priced platinum in catalytic converters by some automobile companies. This has caused a large increase in the cost of palladium. The prices of the two metals are now, in 2002, about the same. Palladium, however, is less resistant to poisoning by sulfur and lead than platinum, but it may prove useful in controlling emissions from diesel vehicles. The metal sells for about $350/tr. oz. ($11/g).
Uses
Palladium is a soft white metal found in copper and nickel ores. The chloride compound of this element was used after the turn of the century for printing and also in combination with platinum for printing. Palladium is a transition metal element used in catalytic reactions involving processes such as hydrogenation. Lindlar Catalyst. In form of gold, silver, and copper alloys in dentistry; for alloy bearings, springs, balance wheels of watches; for mirrors in astronomical instruments; as catalyzer in manufacture of sulfuric acid and in other oxidizing processes; in powder form as catalyst in hydrogenation and in ignition of hydrogen or hydrocarbons with oxygen; the spongy form is used in gas analysis for separating hydrogen from mixtures of gases.
Uses
Palladium’s ability to absorb large amounts of hydrogen makes it an excellent catalyst forchemical reactions as well as catalytic converters for internal combustion engines. Palladiumis also an excellent catalyst for cracking petroleum fractions and for hydrogenation of liquidvegetable oils into solid forms, such as corn oil into margarine. It is also used to purifyhydrogen gas by passing raw H2 gas under pressure through thin sheets of palladium, wherethe pure hydrogen passes through the metal’s crystal structure, leaving behind impurities.Palladium is used to manufacture CO-monitoring devices because of its ability to absorbcarbon monoxide. Palladium is used in the manufacture of surgical instruments, electrical contacts, springs forwatches and clocks, high-quality spark plugs, and special wires and as “white gold” in jewelry.Because it is noncorrosive, it is used as a coating for other metals and to make dental fillingsand crowns.
Uses
Demand for palladium is high for its use in electrical equipment in its metal and paste forms, dentalmaterials in its alloy form, as a composite in implantable medical devices and automobile catalysts owing to its strong catalytic activity for hydrogenation, dehydrogenation, oxidation, and hydrogenolysis reactions.
General Description
This product has been enhanced for energy efficiency.
Preparation & Synthesis
Preparation
It can be made from the ore with dry process in Industrial production; can also copper, nickel sulfide ore preparation of copper, nickel production process as a by-product as raw materials, made by wet smelting. It can also be obtained from the wet process with the byproduct of copper, nickel production from the copper sulfide ore or nickel sulfide ore. The wet method is using the residue of extracted nickel and copper as raw materials, adding aqua for extraction, filtration, adding ammonia and hydrochloric acid to react, thus forming the precipitation of ammonium chloropalladate. After refining, filtration, reduction of ammonium chloropalladate with hydrogen 99.95% finished product of palladium can be obtained.
